Infrared heating device manufacturing method
At present, infrared heating devices are mainly used for the heating, drying, and aging of articles, but due to the absence of a weighing system, the degree of heating of articles, especially the degree of drying of articles, is difficult to grasp.
The invention provides an infrared heating device, which overcomes the disadvantages of the conventional infrared heating device without a weighing system, and enables the user to judge the heating of the article by observing the change of the weight of the article during the heating process. Dry degree. The technical scheme of the utility model is an infrared heating device, which comprises a box body and a heating system. The box body is composed of left and right parts, the left box body is a heating system device installation box, and the right side is an article heating box; A control panel is arranged on the front side surface of the installation box of the heating system device; a box door is arranged on the front side surface of the article heating box; an infrared heating plate is arranged in the article heating box; and also includes a programmable logic controller control system. The programmable logic controller control system includes a weight collection system including a weight signal collector in the article heating box, a weight signal collector connected to the article placement rack, a weight signal collector connected to the signal converter, and a signal The converter is connected to a programmable logic controller that is connected to the display panel mounted on the control panel. The programmable logic controller control system may also include a temperature acquisition system or a humidity acquisition system. The temperature acquisition system includes a temperature signal collector connected to the signal converter, a signal converter connected to the programmable logic controller, and a programmable logic controller connected to the display panel mounted on the control panel. The humidity acquisition system includes a humidity signal collector connected to the signal converter, a signal converter connected to the programmable logic controller, and a programmable logic controller connected to the display panel mounted on the control panel. The beneficial effect of the utility model is that by installing a programmable logic controller control system, the heating of the articles, especially the drying process, can be observed in a timely manner, and the heating degree and the degree of drying of the objects to be heated can be controlled conveniently.
Detailed Implementation
The following is a detailed description of the utility model in accordance with embodiment 1 of the accompanying drawings. As shown in Fig. 1, the components in this embodiment are shown as follows.
- Indicator
- Up and down heating switches
- Left heating switch
- Right heating switch
- Fan switch
- Master Power Switch
- Door handle
- Box Door
- Observation window
Control Panel Includes Display
1, indicator light
2. Up and down heating switches
3. Left heating switch
4. Right heating switch
5. Fan Switch
6. Total Power Switch
7. There is a door on the front side of the article heating box.
9. Door handle
8. There is a transparent area observation window on the door 9
10. As shown in FIG. 2 , the components of this embodiment are as follows:
11. Weight Signal Collector
12. Temperature Signal Collector
13. Humidity Signal Collector
14. Infrared heating plate
15. Article placement rack
16. Vents
17, Ventilation Fans
18. Temperature signal collector
13 is a temperature signal collector of the temperature acquisition system. Humidity signal collector
14 is the humidity signal collector of the humidity acquisition system. Infrared heating plate
15 Installed in the top, bottom, left, right, and back positions of the article heating box, respectively, so that the temperature inside the article heating box is relatively uniform. Attachment to the weight signal collector 12
16, in the article placement rack
16, a tray is placed on the tray, and the tray can be based on the state and nature of the material. An iron tray or a grid type can be used, and the grid type tray can make the water disperse faster when the item is dry.
Claims
1. An infrared heating device comprising a box body and a heating system; the box body is composed of left and right parts, the left box body is a heating system device installation box, and the right side is an article heating box; the heating system The front side surface of the device mounting box is provided with a control panel; the front side surface of the article heating box is provided with a box door; the article heating box is provided with an infrared heating board; and the method also includes a programmable logic controller control system. The programmable logic controller control system includes a weight collection system. The weight collection system includes a weight signal collector installed in the article heating box, a weight signal collector connected to the article placement rack, and a weight signal collector connected to the signal converter. The signal converter is connected to a programmable logic controller that is connected to the display panel mounted on the control panel.
2. An infrared heating device according to claim 1, wherein the programmable logic controller control system further includes a temperature acquisition system, and the temperature acquisition system includes a temperature signal collector and a signal converter. , The signal converter is connected with the programmable logic controller, and the programmable logic controller is connected with the display screen installed on the control panel.
3. An infrared heating device according to claim 1 or 2, wherein the programmable logic controller control system further includes a humidity acquisition system, and the humidity acquisition system includes a humidity signal collector and signal conversion. The device is connected, the signal converter is connected with the programmable logic controller, and the programmable logic controller is connected with the display panel installed on the control panel.
4. An infrared heating device according to claim 1, wherein the infrared heating plates are respectively installed at five positions of upper, lower, left, right, and rear of the article heating box.
